Material and Plating
Plastic parts;PA66,UL94V-0
Welding needle:Brass,Tin plating
Screw:M4,Steel,zinc Plating
Square box:Brass,Nickel platin
Electrical performance
Rated voltage：600V
Rated current：50A
Contact resistance:20mΩ
Insulation resistance:5000MΩ/1000v
Wire diameter:20-6AWG 10mm2
Withstanding Voltage:AC3000V/1Min
Mechanical properties
Ambient temperature:-40℃_~+105℃
MAX Soldering:+250℃,5s
Torque:1.2Nm
Strip length:10mm
