Material and Plating
Plastic parts;PA66,UL94V-0
Welding needle:Brass,Tin plating
Screw:M4,Steel,Nickel Plating
Electrical performance
Rated voltage：300V
Rated current：20A
Ambient temperature:-40℃_~+105℃
MAX Soldering:+250℃,5s
Withstanding Voltage:AC2000V/1Min
Contact resistance:20mΩ
Insulation resistance:5000MΩ/1000v
Wire diameter:22-14AWG
Maximum locking torque:10kg.cm
