Material and Plating
Spacing:7.62mm
Plastic parts;PA66,UL94V-0
Welding needle:Brass,Tin plating
Screw:M3.0,Steel,Nickel Platin
Electrical performance
Rated voltage：300V
Rated current：15A
Ambient temperature:-40℃~+105℃
MAX Soldering:+250℃,5s
Withstanding Voltage:AC2000V/1Min
Contact resistance:20mΩ
Insulation resistance:500MΩ/DC500V
Wire diameter:22-12AWG 2.5mm2
Torque:0.5Nm
